Product Description

2 port High Speed Serial RS-232 + 1 port Parallel PCIe card support 5V/12V/RI Selectable and Standar

Minimum Order Quantity : Under 1000
Are samples available for this product? : Yes
Delivery Date : 3Day(s)
Current Export Markets : Worldwide, Europe, North America, Mid East/Western Asia, Central/South America, Asia, Australia/Oceania, Taiwan, China, India, Southeast Asia, Africa

Language : English

Features and Benefit

Expands 2 RS-232 com ports and 1 port Parallel for your system
High Speed Baud Rate up to 921.6Kbps
Design to meet PCI Express 2.0 Gen 1 compliant
Supports PCI Express x1, x2, x4, x8, and x16 Lane
Power Supply through communication line(RI signal)
Built-in 15KV ESD protection
Supports Industrial Specification
256 byte FIFOs integrated UART
Supports 5V/12V/RI Selectable
Parallel – Compatibility mode, Nibble mode, Byte mode, EPP mode, and ECP mode)
16byte : SPP/ECP mode
I/O Address remap – RS-232 for 3F8, 2F8, 3E8, and 2E8. Parallel – 378 and 278
Supports Microsoft Windows, Linux
